3. Launch the TFTP server and go to the File menu→Configure→Security to change the TFTP server's default
setting from "Receive Only" to "Transmit Only" for the firmware upgrade;
4. Start the TFTP server and configure the TFTP server in the UCM6100 web configuration interface;
5. Configure the Firmware Server Path to the IP address of the PC;
6. Update the changes and reboot the UCM6100.
End users can also choose to download a free HTTP server from http://httpd.apache.org/ or use
Microsoft IIS web server.
Backup
The UCM6100 configuration can be backed up locally or via network. The backup file will be used to restore the
configuration on UCM6100 when necessary.
Backup/Restore
Users could backup the UCM6100 configurations for restore purpose under Web
GUI→Maintenance→Backup→Backup/Restore.
Click on to create a new backup file. Then the following dialog will show.
Figure 290: Create New Backup
