UCM6100 Series User Manual
Version 1.0.18.13
SYSTEM SETTINGS
This section explains configurations for system-wide parameters on the UCM6100. System settings are under
“System Settings” tab on UCM6100 Web GUI. System settings include User Management, Network Settings,
Firewall/Security Settings, Change Password, LDAP server, HTTP server, Email settings, Time Settings, NTP
Server, Recordings Storage and Login Timeout settings.
HTTP Server
The UCM6100 embedded web server responds to HTTP/HTTPS GET/POST requests. Embedded HTML pages
allow the users to configure the PBX through a Web browser such as Microsoft IE, Mozilla Firefox and Google
Chrome. By default, the PBX can be accessed via HTTPS using Port 8089 (e.g., https://192.168.40.50:8089).
Users could also change the access protocol and port as preferred under Web GUI→System Settings→HTTP
Server.
Table 6: HTTP Server Settings
Redirect From Port 80
Enable or disable redirect from port 80. On the PBX, the default access
protocol is HTTPS and the default port number is 8089. When this option
is enabled, the access using HTTP with Port 80 will be redirected to
HTTPS with Port 8089. The default setting is "Enable".
Protocol Type
Select HTTP or HTTPS. The default setting is "HTTPS". This is also the
protocol used for zero config when the end point device downloads the
config file from the UCM6100.
Port
Specify port number to access the HTTP server. The default port number
is 8089.
Enable IP whitelist
If enabled, only the IP address on the permitted IP list will be allowed to
access the UCM’s web GUI.
Permitted IP(s)
Add an IP address to the list of allowed IPs to access UCM’s web GUI.
Ex: 192.168.6.233 / 255.255.255.255
Certificate Options
Select the mode to download SSL certificates for web server, two modes
are available:
• Manually Upload certificate: Upload the files while respecting
size and format.
• Automatically request certificate: enter domain from which to
request the certificate files.
TLS Private Key
Upload private key for the built-in http server.
Note: The size of the key file must be under 2MB and the it will be renamed
as "private.pem" automatically.
