P a g e | 407

UCM6100 Series User Manual

Version 1.0.18.13

Figure 297: Cleaner

Table 132: Cleaner Configuration

Enable CDR Cleaner

Enable the CDR Cleaner function.

Clean Files in External

Device

If enabled the files in external device (USB/SD card) will be atomically cleaned

up as configured.

CDR Clean Time

Enter 0-23 to specify the hour of the day to clean up CDR.

Clean Interval

Enter 1-30 to specify the day of the month to clean up CDR.

Enable Queue Statistics

Report Cleaner

Enable scheduled queue log cleaning. By default, is disabled.
