UCM6100 Series User Manual
Version 1.0.18.13
Specify which Music On Hold class to suggest to the bridged channel when putting
them on hold.
The maximum duration of call-blocking.
The maximum call duration (in seconds). The default value 0 means no limit.
Custom Call-info
for Auto Answer
If enabled, when a call is sent to this extension from UCM, the SIP INVITE message
will contain a Call-info header indicating auto answer.
If disabled, UCM won't invite the extension when it's already in a call, and will do the
same work as the user is busy.
Note: the option only works when the caller dials the extension directly.
Table 37: SIP Extension Configuration Parameters→Specific Time
Click to add Time Condition to configure specific time for this extension.
Create New IAX Extension
The UCM6100 supports Inter-Asterisk eXchange (IAX) protocol. IAX is used for transporting VoIP telephony
sessions between servers and terminal devices. IAX is like SIP but also has its own characteristic. For more
information, please refer to RFC 5465.
To manually create new IAX user, go to Web GUI→Extension/Trunk→Extensions. Click on "Add" and a new
dialog window will show for users which need to make sure first to select the extension type to be IAX Extension
before proceeding to fill in the extension information. The configuration parameters are as follows.
Table 38: IAX Extension Configuration Parameters→Basic Settings
The extension number associated with the user.
Configure the CallerID Number that would be applied for outbound calls from this
user.
Note: The ability to manipulate your outbound Caller ID may be limited by your VoIP
provider.
Assign permission level to the user. The available permissions are "Internal", "Local",
"National" and "International" from the lowest level to the highest level. The default
setting is "Internal".
Note: Users need to have the same level as or higher level than an outbound rule's
privilege to make outbound calls using this rule.
