P a g e | 324

UCM6100 Series User Manual

Version 1.0.18.13

PBX Settings/NAS

The UCM supports adding and backing up recordings to a network-attached storage (NAS) server. To configure

a NAS server.

Table 95: NAS Settings

Enable

Enabled / Disable the NAS recording functionality.

Host

Configure the Domain or IP address of the NAS server.

Note: Currently, only IP addresses are supported in the Host/IP field.

Share Name

Specify the name of the shared folder.

Username

Specify the account username to access the NAS server.

Password

Configure the account password to access the NAS server.

Status

If configured correctly, the Status field will show “Mounted”, and the newly

added NAS server will be shown on the Mounted Netdisk List. Additionally, the

NAS will appear as a selectable storage option in the PBX Settings->Recording

Storage page and CDR->Recording Files page.
