Select "All On" "All Off" or "Blinking" and check LED status.
• RTC Test Patterns
Select "2022-02-22 22:22" or "2011-01-11 11:11" to start the RTC (Real-
Time Clock) test pattern. Then check the system time from LCD idle screen
by pressing "DOWN" button, or from web GUI→System Status→General
page. Reboot the device manually after the RTC test is done.
• Hardware Testing
Select "Test SVIP" to perform SVIP test on the device. This is mainly for
factory testing purpose which verifies the hardware connection inside the
device. The diagnostic result will display in the LCD after the test is done.
• Protocol: Web access protocol. HTTP or HTTPS. By default, it's HTTPS
• Port: Web access port number. By default, it's 8089
• Enable SSH: Enable SSH access.
• Disable SSH: Disable SSH access.
By default, SSH access is disabled.
Use the LED Indicators
The UCM6100 has LED indicators in the front to display connection status. The following table shows the status
definitions.
Table 4: UCM6102/UCM6104 LED Indicators
LAN
WAN
USB
SD
FXS (Phone/Fax)
FXO (Telco Line)
Solid: Connected
Flashing: Data Transferring
OFF: Not Connected
To Next Page
