Table 3: LCD Menu Options
View Events
• Critical Events
• Other Events
Device Info
• Hardware: Hardware version number
• Software: Software version number
• P/N: Part number
• WAN MAC: WAN side MAC address (UCM6102 only)
• LAN MAC: LAN side MAC address
• Uptime: System up time
Network Info
For UCM6104/UCM6108/UCM6116:
• LAN Mode: DHCP, Static IP, or PPPoE
• LAN IP: IP address
• LAN Subnet Mask
For UCM6102:
• WAN Mode: DHCP, Static IP, or PPPoE
• WAN IP: IP address
• WAN Subnet Mask
• LAN IP: IP address
• LAN Subnet Mask
Network Menu
For UCM6104/UCM6108/UCM6116:
• LAN Mode: Select LAN mode as DHCP, Static IP or PPPoE
• Static Route Reset: Click to reset the static route setting
For UCM6102:
• WAN Mode: Select WAN mode as DHCP, Static IP or PPPoE
• Static Route Reset: Click to reset the static route setting
Factory Menu
• Reboot
• Factory Reset
• LCD Test Patterns
Press "OK" to start. Then press "Down" button to test different LCD patterns.
When done, press "OK" button to exit.
• Fan Mode
Select "Auto" or "On".
• LED Test Patterns
