UCM6100 Series User Manual
Version 1.0.18.13
User can create a new Parking lot by clicking on button “Create New Parking Lot” :
Figure 200 : New Parking Lot
Table 88 : Parking Lot
• Default Extension: 700
• During an active call, initiate blind transfer and then enter this
code to park the call.
• Set a name to the parking lot
• Default Extension: 701-720
• These are the extensions where the calls will be parked, i.e.,
parking lots that the parked calls can be retrieved.
• If checked, the parking lot number can be used as extension.
The user can transfer the call to the parking lot number to park
the call. Please note this parking lot number range might conflict
with extension range.
• Default setting is 300 seconds and the maximum limit is 99.999
seconds.
• This is the timeout allowed for a call to be parked. After the
timeout, if the call is not picked up, the extension who parks the
call will be called back.
Select the Music on Hold Class.
Configures a callback failover destination when the extension that
is called back is busy. The call will be routed to the destination
number and this reduces the chance of dropping parked calls.
Ring All Callback on Timeout
If enabled, all registered endpoints of the extension will ring when
callback occurs. Otherwise, the original endpoint will be called back.
Forward to destination on
timeout
If enabled, the call will be routed to the configured destination upon
timeout. Otherwise, the call will be routed back to the original caller.
