UCM6100 Series User Manual
Version 1.0.18.13
Enable automatic recording for the calls using this extension. The default setting is
disabled. The recording files can be accessed under Web GUI→CDR→Recording
Files.
• If set to “Yes”, users can skip entering the password when making outbound calls.
• If set to “By Time”, users can skip entering the password when making outbound
calls during the selected time condition.
• If set to “No”, users will be asked to enter the password when making outbound
calls.
Time Condition for
Skip Trunk Auth
If “Skip Trunk Auth” is set to “By Time”, select a time condition during which users can
skip entering password when making outbound calls.
Configure personal password when making outbound calls via trunk.
If enabled, the extension will be added to LDAP Phonebook PBX lists.
Configure the Music On Hold class to suggest to the bridged channel when putting
them on hold.
The maximum duration of call-blocking.
Table 41: IAX Extension Configuration Parameters→Specific Time
Click to add Time Condition to configure specific time for this extension.
Create New FXS Extension
The UCM6100 supports Foreign eXchange Subscriber (FXS) interface. FXS is used when user needs to connect
analog phone lines or FAX machines to the UCM6100.
To manually create new FXS user, go to Web GUI→Extension/Trunk→Extensions. Click on "Add" and a new
dialog window will show for users which need to make sure first to select the extension type to be FXS Extension
before proceeding to fill in the extension information. The configuration parameters are as follows.
Table 42: FXS Extension Configuration Parameters→Basic Settings
The extension number associated with the user.
Select the FXS port to be assigned for this extension.
Configure the CallerID Number that would be applied for outbound calls from this
user.
Note: The ability to manipulate your outbound Caller ID may be limited by your VoIP
provider.
