Cleaner Options

Enable Conference

Schedules Cleaner

If this option is enabled, conference schedules will be automatically cleaned as

configured.

Conference

Schedules Clean

Time

Enter the clean time (in hours). The valid range is from 0 to 23.

Clean Interval

Enter the clean interval (in days). The valid range is from 1 to 30.

• Show/hide Conference Schedule Table

Enable this option will allow Web GUI to display scheduled conference in Conference Schedule Table. Please

see figure below.

Figure 128: Conference Schedule
