P a g e | 98

UCM6100 Series User Manual

Version 1.0.18.13

POP/POP3 Server Address

Configure the POP/POP3 server address for the configured username

Example: pop.gmail.com

POP/POP3 Server Port

Configure the POP/POP3 server port for the configured username

Example: 995

Display Name

Specify the display name in the FROM header in the Email.

Sender

Specify the sender's Email address.

For example: pbx@example.mycompany.com.

The following figure shows a sample Email setting on the UCM6100, assuming the Email is using 192.168.6.202

as the SMTP server.

Figure 50: UCM6100 Email Settings
