FC2250-UM-251-9370 7-53
7. DISASSEMBLY AND ADJUSTMENT
(3) Afx the exible cables and the exible guides as shown in gure below.
FLEXG2
J671
35mm
35mm
J561
FLEXG1
35mm
J453
1 35
J452
J561
FLEXG1
Remove protection lables when installing the flexible cable to the Y bar.
J671
