1. INTRODUCTION
1. INTRODUCTION
1.1 Model Names and Basic Specications
Model Media hold down method Cutting area
FC2250-60VC Vacuum suction 610 (X) x 920 (Y) mm
FC2250-120MG Magnetic
1200 (X) x 920 (Y) mmFC2250-120ES Electrostatic adhesion
FC2250-120VC Vacuum suction
FC2250-180ES Electrostatic adhesion 1740 (X) x 920 (Y) mm
FC2250-180VC Vacuum suction
1.2 Standard Accessories
Item Description Q’ty
Power cable 1
Cutter pen set PPA31-CB15B, CB15U-2SP, CB15U-K30-5SP 1 set
Water based ber-tip pen KF552-BK 1
Sheet holder plates For MG models only (2 large, 2 medium, 4 small) 1 set
Hexagon wrench For M4 bolts 1
Height adjustment plates 10 mm, 4 mm height 1 of each
Durable exible hose For VC models only, 1.5 m to 5 m (can expand/contract)
Connection bore diameter: Ø38mm (-60), Ø58mm (-120/180)
1
Hose band For VC models only, Ø38mm (-60), Ø58mm (-120/180) 2
Vacuum pump installation base For VC models only 1
USB cable 1
CD-ROM User’s manual, Driver, other software 1
CAUTION
• The vacuum pump is an option. It is not provided with the VC models.
• Make sure that the vacuum pump used with a VC model is afxed with either a label showing compliance
with the relevant safety standard or with the CE marking.
