FC2250-UM-251-9370 11-22
11. BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS
11.13 Miscellaneous
792807030 Cable, X relay board to X home sensor CA223303 1
Cable, X relay board to X motor CA2291-51 1
692247070
Cable, Power supply board to power supply relay board
CA504207 1
692247060
Cable, Power supply board to power switch
CA504206 1
692807142 Cable, Key relay board to LCD CA2232112B 1
692807131
Cable, Key relay board to chart hold switch
CA2232113A 1
692236112 Cable, Main relay board to key relay board CA2290-01B 1
692236133 Cable, Main relay board to X relay board CA2290-03C 1
692247080
Cable, Main relay board to X exible board
CA504208 (FC2250-60/120) 1
692247090
Cable, Main relay board to X exible board
CA504209 (FC2250-180) 1
122927511
Cable, X exible board to High voltage board
CA2292-51A (FC2250-180) 1
692236211
Cable, X exible board to High voltage board
CA2292-41D (FC2250-60/120) 1
108901173 Cable, AC inlet to power switch CA08917C 1
692236041 Cable, AC inlet to power switch CA306004 1
692236051 Cable, AC inlet to power switch CA306005 1
692256010 Cable, Main board to main relay board CA612101 1
692256021 Cable, Main board to main relay board CA612102A 1
692256031 Cable, Main board to main relay board CA612103A 1
692256041 Cable, Main board to power supply board CA612104A 1
692256051
Cable, 2 pen relay board to pen exible board
CA612105A 1
110006060
Flexible Cable, 2 pen board to pen 1 moving coil
FPC10002 1
122936100
Flexible Cable, 2 pen board to height sensor
FPC2293100 2
122936110
Flexible Cable, 2 pen board to pen 2 moving coils
FPC2293110 1
692256061
Cable, 2 pen board to ARM sensor
CA612106A 1
162291100 Y exible Cable FCA2291010 2
692256220 X exible Cable FPC612122 (FC2250-180) 1
692256230 X exible Cable FPC612123 (FC2250-60/120) 1
692807051 Cable, X-Y relay board to Y home sensor CA2232503A 1
520100241 AC Cable VM1182-1276.5M
520100330 UL/CSA AC Cable UL/CSA Code SJT
500050024 CEE AC Cable VM0306B-0304B2M
520000022 BS AC Cable GRCK-B0
520100103 SUS AC Cable PISEV-H05VV-F-1C
520100098 SAA AC Cable SAA Standard Cable Set 3M
520000005 BS AC Cable (P) Z-VCTF-OR-BS
