FC2250-UM-251-9730 6-1
6. LIST OF TOOLS
6. LIST OF TOOLS
6.1 Tools
No. Tool Adjustment Item
1 Correx gauge (Dial tension gauge) 500 gf Pen force adjustment
2 Correx gauge (Dial tension gauge) 300 gf Pen force and belt tension adjustment
3 Correx gauge (Dial tension gauge) 50 gf Pen force adjustment
4 Cutter pen Pen force adjustment
5 Push-pull gauge 5 kg Belt tension adjustment
6 Push-pull gauge 2 kg Belt tension adjustment
7 Push-pull gauge 1 kg Belt tension adjustment
8 Glass scale (1000 mm) Distance adjustment
9 Ceramic pen (ø0.2 mm) Distance adjustment
10 PC, Centronics I/F cable Firmware update
11 Phillips screwdriver M5
12 Phillips screwdriver M4
13 Phillips screwdriver M3
14 Phillips screwdriver M2
15 Small flat-head screwdriver For adjusting the variable resistors on the board
16 Hexagon wrench 1.5 mm span For M3 set-screws
17 Hexagon wrench 2.0 mm span For M4 set-screws
18 Hexagon wrench 2.5 mm span For the pen block set-screws
19 Box wrench 5.5 mm span For removing M3 nuts
20 Bond-type adhesive For securing screws
21 Double-sided tape (10 mm, 5 mm wide) For securing the FPC cables
22 Ethyl alcohol For cleaning the electrostatic adhesion plate and rail
23 Metallic ruler (about 15 cm long) For adjusting the belt tension
24 Multimeter For checking damaged or shorted wires
25 Silicon Grease (P/N308002003) To avoid the belt skipping.
