GRAPHTEC FC2250 - The Y Home Sensor Was Replaced; The Registration Mark Sensor Was Replaced; The X Or Y Motor Was Replaced

FC2250-UM-251-9370 8-4
8. ELECTRICAL ADJUSTMENTS
8.2.4 The Y home sensor was replaced
When the Y home was exchanged, an electric adjustment is executed by the following procedure.
8.9 Adjusting the Home Position
8.5 Set the DIP Switches setting to the adjustment mode
End of Adjustment
8.5 Set the DIP Switches setting to the normal mode
8.12 Adjusting the Distance Accuracy and the perpendicularity
8.2.5 The registration mark sensor was replaced
When the registration mark sensor was exchanged, an electric adjustment is executed by the following
procedure.
8.14 Adjusting the Registration Mark Sensor Sensitivity
8.15 Adjusting the Offset of the Registration Mark Sensor
8.5 Set the DIP Switches setting to the adjustment mode
End of Adjustment
8.5 Set the DIP Switches setting to the normal mode
8.2.6 The X or Y motor was replaced
When the X or Y motor was exchanged, an electric adjustment is executed by the following procedure.
8.9 Adjusting the Home Position
8.5 Set the DIP Switches setting to the adjustment mode
End of Adjustment
8.5 Set the DIP Switches setting to the normal mode
8.12 Adjusting the Distance Accuracy and the perpendicularity
