GRAPHTEC FC2250 - Y Flexible Cable

FC2250-UM-251-9370 7-45
7. DISASSEMBLY AND ADJUSTMENT
7.5.7 Y Flexible Cable
How to detach the Y exible cable
(1) Detach the pen block from the Y bar (See the section 7.3.1).
(2) Detach the Y bar (See the section 7.5.1).
(3) Detach the Y belt (See the section 7.5.5).
(4) Disconnect the cable from the connector J62 on the pen exible relay board.
(5) Remove the M3L4 binding head screw holding the Y exible cable xing bracket, then detach it.
M3L4 binding head screw
Y exible cable xing bracket
(6) Remove the M3L4 binding head screw holding the Y sensor dog, then detach it.
M3L4 binding head screw
Y home sensor dog
