FC2250-UM-251-9370 8-2
8. ELECTRICAL ADJUSTMENTS
8.2 Flowchart of the Adjustment Sequence
Flowchart of the Adjustment Sequence for the FC2250 series.
8.2.1 The main board was replaced
When the main board was exchanged, an electric adjustment is executed by the following procedure.
8.6 Updating the System Firmware
8.9 Adjusting the Home Position
8.10 Adjusting the Pen Height
8.11 Adjusting the Pen Force
8.12 Adjusting the Distance Accuracy and the perpendicularity
8.13 Adjusting the Pen Interval
8.14 Adjusting the Registration Mark Sensor Sensitivity
8.7 Clearing the Non-Volatile RAM
8.8 Gain Value Input
8.15 Adjusting the Offset of the Registration Mark Sensor
8.5 Set the DIP Switches setting to the adjustment mode
End of Adjustment
8.5 Set the DIP Switches setting to the normal mode
