GRAPHTEC FC2250 - Drive Unit

FC2250-UM-251-9370 10-6
10. PARTS LIST
10.5 X Drive Unit
No. Part No. Description Q’ty Remarks Rank
3 311060820 Bearing 4 F608ZZMC3PS2S C
4 022904221 Bearing Spacer 2 D
5 022903590 Pulley Shaft, Right 2 C
6
022904500 X Belt
2
S2ML2350, FC2250-60 A
022904510 X Belt 120 S2ML3200, FC2250-120 A
022904520 X Belt EX S2ML4200, FC2250-180 A
7 022903673 Roller Lever 2 C
8 022900400 Roller ø27 3 C
9 022903535 X Slider 1 C
10 020003131 Roller 9 B
11 022903681 Roller Collar A 2 C
12 022903665 Flexible Plate 1 C
13 022903872 Lower Bracket, Right 1 C
14 022903912 X Roller Collar 1 C
15 311068820 Bearing 6 F688ZZMC3PS2S B
16 022902541 Drive Pulley R 1 S2M C
17 022903262 Pulley 1 60Z-TN C
18 378412061 Notched Synchrony Belt 1 120TN15-15G B
19 022903181 Drive Shaft, Rear 1 C
20 022903151 Pulley 1 30Z-TN C
21 022903105 Gear Box 1 C
22 022903113 X-Motor Bracket 1 C
23 022903122 Box Fitting Plate 2 C
24 053206101 Motor Pulley 1 Z22 B
25 022903133 Intermediate Shaft 1 C
27 022900360 Drive Collar C 1 C
28 022903250 Pulley 1 99Z-TN C
29 375311001 Notched Synchrony Belt 1 120TN15 B
30 022900352 X Gear Space Board 1 C
32 621472201 X Motor Cover 1 C
33 022903242 Drive Shaft M 1 C
34 022903291 Coupling 2 C
35 022903212 Collar 2 C
36 022902531 Drive Pulley F 1 S2M C
38 022903191 Drive Shaft, Front 1 C
39 022903853 Lower Bracket, Front 1 C
41 022903524 X Slider, Front 1 C
42 022903912 X Roller Collar 5 C
43 022903653 Belt Plate D 1 C
44 395030350 Space Shaft 1 ASB335E C
45 022903580 Pulley Shaft, Front 1 C
46 022903643 Belt Plate C 1
49
022901320 X Rail, Front 60
1
FC2250-60 D
022903500 X Rail, Front 120 FC2250-120 D
022903761 X Rail, Front 180 FC2250-180 D
51
022901310 X Rail, Rear 60
1
D
022903512 X Rail, Rear 120 D
022903773 X Rail, Rear 180 D
52 022903632 Belt Plate B 2 D
53 022903693 Roller Collar B 2 D
54 022904213 Spacer ø04-1.5 2 D
56 362200005 Rubber Foot 1 SJ5008 D
E1 792256708 X Home Sensor Board 1 PN6121-12C A
E2 792290708 X Motor 1 UGFMEDA5LGR28 A
E3
692256221 X Flexible Cable 60/120
1
FC2250-60/120 A
692256231 X Flexible Cable 180 FC2250-180 A
