GRAPHTEC FC2250 - High Voltage Board (Pr31001 C)

FC2250-UM-251-9370 11-11
11. BLOCK DIAGRAMS AND CIRCUIT DIAGRAMS
11.10 High Voltage Board (PR31001C)
+24V GND OPEN
1 2 3
C1
22uF/35V
C2
HVT
+
+
10uF/15V
C4
D1
471/6KV
C5
R5 510K
R6
1 2 3
V- PPEN GND
1625-03R
510K
471/6KV
R1
R3
D5
D5
1S1585
D2
TFR2T
TFR2T
D3
1S1585
RD4.7E
R2
C3
222
100K
R4
10K
1K
1K
Q1
3
TR1
2
7 5
4 1
2SC2719L
IL-G-3S-S3S2
