GRAPHTEC FC2250 - Y Drive Section

FC2250-UM-251-9370 10-9
10. PARTS LIST
10.6 Y Drive Section
No. Part No. Description Q’ty Remarks Rank
1 621473401 Y Gear Box 1 D
2 621473411 Y Motor Bracket 1 D
3 022903363 Pulley 1 88Z-TN C
4 022903372 Pulley 1 44Z-TN C
5 022903331 Y Pulley Shaft 1 C
6 621473420 Y Motor Cover 1 C
7 022903352 Y Bar Plate 2 C
8 022903381 Shaft ø5 1 C
9 022903535 X Slider R 1 C
10 053206101 Motor Pulley 1 22Z C
11 311068820 Bearing 2 F688ZZ C
12 311060520 Bearing 2 F605ZZ C
13 379011002 Notched Synchro Belt 1 79TN15-10.0K B
14 375311001 Notched Synchro Belt 1 120TN15-10.0W B
15 362200005 Rubber Foot 1 SJ-5008 C
16 022903430 F22 Pulley 1 C
20 022904012 Y Bar 1 D
21 022904033 Y Pulley Bracket 1 D
22 022904230 Y F End 1 D
23 022904063 Y Front Bracket 1 D
24 022904072 Y Front Plate 3 D
25 022904080 Bearing Shaft 1 C
26 621473340 Y End Front Cover 1 C
27 022904500 Y Belt 1 S2ML2350 B
28 022904221 Bearing Spacer 1 C
29 022904331 Y-Flexible Cable Reinforcement 2 A
30 311060820 Bearing 2 F608ZZMC3PS2S B
31 022904252 Y Stopper 1 C
40 022904025 Y Slider 1 C
622563400 Y Slider SH For FC2250(SH/PM) Pen Block Assy
41 621473310 Plate PUF 1 D
622563410 Plate PUF SH For FC2250(SH/PM) Pen Block Assy
42 022904131 Offset Pin A 2 D
43 022904151 Offset Pin C 2 D
44 622563110 Pen PCB Bracket 1 D
45 622563300 Y PCB Bracket 1 D
46 022904182 Flexible Guard Bracket 1 D
47 022904194 Flexible Plate 1 D
48 022904204 Y Sensor Holder 1 D
49 022904213 Collar ø4-1.5 6 D
50 022904303 Roller Plate 1 D
51 022903632 Belt Holder B 2 D
52 020003131 Roller 4 B
53 022900410 Roller ø12 8 B
54 395830050 Spacer 2 SB-305 D
55 022904322 Y Roller Collar 4 D
60 622564000 MC Base Block 1 D
61 090113201 Long Magnetic Circuit Board A 2 A0000 D
62 022902280 Slide Shaft Assembly 2 D
63 021500622 50 Slide Arm 1 D
64 022906323 Hall IC Bracket 2 D
65 053203390 Guide Shaft 2 D
66 310069220 Bearing 4 BB692ZZMC3PS2S D
67 053203350 MC Up Spring 1 D
68 340804012 O Ring,S4 2 D
69 034004591 Offset Pin 2 D
70 021500632 Cutter Holder 2 D
71 621113581 Thumb Screw L14 2 L14 C
72 302200069 Spacer CB307 2 D
73 622564010 2-Pen Cover 1 C
622564601 2-Pen Cover (PM)
For FC2250(PM) Pen Block Assy
74 621473300 2-Pen Block Plate 1 D
622564300 2-Pen Block Plate (SH)
For FC2250(SH/PM) Pen Block Assy
