GRAPHTEC FC2250 - Right Rear Cover; Left Rear Cover

FC2250-UM-251-9370 7-2
7. DISASSEMBLY AND ADJUSTMENT
7.1.3 Right Rear Cover
How to detach the right rear cover
(1) Remove the M3L8 self-tapping screw holding the right rear cover, and then detach it.
Right rear cover
M3L8 Self-tapping screw
How to reinstall the right rear cover
(1) Reattach the right side rear cover in the reverse order in which it was detached.
7.1.4 Left Rear Cover
How to detach the left rear cover
(1) Remove the M3L8 self-tapping screw holding the left rear cover, and then detach it.
Left rear cover
M3L8 Self-tapping screw
How to reinstall the left rear cover
(1) Reattach the left rear cover in the reverse order in which it was detached.
