GRAPHTEC FC2250 - 10 Parts Lists; Mainframe

FC2250-UM-251-9370 10-1
10. PARTS LIST
10. PARTS LISTS
10.1 Mainframe
No. Part No. Description Q’ty Remarks Rank
E1 792256707 X Relay Board 1 PN6121-11C Assembly A
E2 792256702 X Flex. Board 1 PN6121-03 Assembly A
E3 775421740 High Voltage Board 1 PR31001C Assembly A
E4
692247080 Y Cable 60/120
1
CA504208 A
692247090 Y Cable 180 CA504209 A
E5 692236134 X Cable 1 CA2290-03 A
1 621474130 Corner Cover (Rear Right) 1 C
2
792229700 Electrostatic Panel 12
1
FC2250-120ES C
792229701 Electrostatic Panel 18 FC2250-180ES C
772290080 Magnetic Sheet 90 FC2250-120MG C
792200706 Vacuum Panel 60 FC2250-60VC C
792201220 Vacuum Panel 120 FC2250-120VC C
792201260 Vacuum Panel 180 FC2250-180VC C
3 022907302 Power Board Cover 1 C
4 621474110 Corner Cover (Front Right) 1 C
5 022907323 Plate Nut 4 M4-18 D
6 022907293 Plate Nut 8 M4-12 D
7 022907233 Frame End Holder Plate 2 C
8
022901330 Tray 60
1
FC2250-60 C
022900740 Tray 120 FC2250-120 C
022900750 Tray 180 FC2250-180 C
9
022907410 Main Frame
2
FC2250-120/180 D
622301660 Main Frame 60 FC2250-60 D
10 621474100 Corner Cover (Front Left) 1 C
12 792256731 FC2250 Pen Block Assembly 1 PM Type A
13 621474120 Corner Cover (Rear Left) 1 C
14 022907253 Board Cover 2 C
15 621474140 Side Cover 2 C
16
022903753 X Flexible Guide 120 Right
1
FC2250-120 C
022903722 X Flexible Guide 180 Right FC2250-180 C
17
022901340 X Flexible Guide 60 Left
1
FC2250-60 C
022903722 X Flexible Guide 120 Left FC2250-120 C
022903781 X Flexible Guide 180 Left FC2250-180 C
