GRAPHTEC FC2250 - 5 Recommended Parts List

FC2250-UM-251-9730 5-1
5. RECOMMENDED PARTS LIST
5. RECOMMENDED PARTS LIST
No. Part No. Description
Q'ty
Remarks
1 792256700 Main Board 1
2 792256706 2-Pen T Board 1
3 792256711 FC2250 Pen Block Assy 1 Discontinued
792256721 FC2250 (SH) Pen Block Assy Discontinued
792256731 FC2250 (PM) Pen Block Assy
4 682247030 Control Panel Switch 1 Same as FC2240
5 792290708 X-Motor 1
6 792240706 Y-Motor 1
7 682247530 Power Supply LEP100F-36 1
8
692256221 X-Flexible Cable, FPC612122 1 FC2250-60/120
692256231 X-Flexible Cable, FPC612123 1 FC2250-180
9 162291101 Y-Flexible Cable FCA2291010A 2
10 022904331 Y-Flexible Cable Reinforcement 2
9+10 772258520 Y-Flexible Cable Assembly 1 Item 9 and 10
11
022904500 X-Belt S2ML2350 2 FC2250-60
022904510 X-Belt S2ML3200 2 FC2250-120
022904520 X-Belt S2ML4200 2 FC2250-180
12 022904500 Y-Belt S2ML2350 1
13 792256701 Main Relay Board 1
14 772247591 Power Relay Board, PN5042-04 1
15 792256703 X-Y Relay Board 1
16 792256708 FC2250 X Home Sensor Board 1
17 792256709 FC2250 Y Home Sensor Board 1
18 792256710 FC2250 Registration Mark Sensor Assy 1
19 792256702 FC2250 X FPC Relay Board 1
20 792256704 FC2250 Y FPC Board 1 1
21 792256705 FC2250 Y FPC Board 2 1
