FC2250-UM-251-9370 10-10
10. PARTS LIST
No. Part No. Description Q’ty Remarks Rank
75 022902451 2P2 Slide Arm 1 D
76 302200076 MC Up Spring E537 1 D
77 621473320 Y Slider Cover T 1 C
622563420 Y Slider Cover T SH
For FC2250(SH/PM) Pen Block Assy C
78 621473330 Plate PUR 1 D
622563430 Plate PUR SH
For FC2250(SH/PM) Pen Block Assy D
622563440 Angle PU SH
For FC2250(SH/PM) Pen Block Assy D
79 622563100 RMS Unit Base Bracket 1 D
80 621473210 Pen Number Label 1 D
81 622563210 RMS Slider 1 D
82 622563200 Sensor Base Bracket 1 D
83 311540114 Linear Guide 1 LL15-40 D
85 622563220 RM Sensor Bracket 1 D
86 622563240 RMS Hood 1 D
87 622563230 RMS Bracket Lid 1 D
88 792256711 2250-Pen Block Assembly 1 Discontinued A
792256721 FC2250(SH) Pen Block Ass Discontinued
792256731 FC2250(PM) Pen Block Assy
E1 792256703 X-Y Relay Board 1 PN6121-04C A
E2 792240706 Y Motor 1 UGFMED-B5LGRA6 A
E3 162291101 Y-Flexible Cable 2 FCA2291010A
B
772258520 Y Flexible Cable Assembly 1
Item E3 x 2 and No.29 x 2 A
E4 305320007 Moving Coil 3 PL-326B D
682132522 Moving Coil (PM)
PM805, FC2250(PM) Pen Block Assy D
E5 110006060 MC Flexible Cable 1 FPC10002 D
682256210 Flexible Cable, MC1 (PM)
FPC6121-02 FC2250(PM) Pen Block Assy
E6 792240702 Height Sensor 2 D
E7 792256709 Y Home Sensor Board 1 PN6121-13C A
E8 792256704 Pen Flex. Board 1 1 PN6121-06C A
E9 792256705 Pen Flex. Board 2 1 PN6121-08C A
E10 692256051 2-Pen Cable 1 CA612105A B
E11 792256706 2-Pen Board Assembly 1 PN6121-08C A
E12 122936111 MC T Flexible Cable 1 FPC2293110A D
682256220 Flexible Cable, MC2 (PM)
FPC6121-02 FC2250(PM) Pen Block Assy
E13 500052472 RMS Solenoid 1 TDS-05B-DC12V C
E14 792256710 Registration Mark Sensor Assy 1 A
