8. ELECTRICAL ADJUSTMENTS
(9) Adjust the deviation of Pen 1 based on the lines drawn by Pen 2.
To adjust the X-axis deviation, press the [F2] key and then use the
and keys to adjust the
numeric value.
To adjust the Y-axis deviation, press the [F4] key and then use the
and keys to adjust the
numeric value.
TheX=andY=valuescanbespeciedinarangeof-8.0to+8.0mm.
(10) Press the ENTER key to register your INTERVAL ADJUST setting.
(11) Press the PAUSE key to cancel PAUSE mode, and the turn off the plotter.
(12) Return the DIP switch to its normal settings.
Note: Your INTERVAL ADJUST setting is retained in the plotter’s internal memory even while the
plotter is turned off.
