9. TROUBLESHOOTING
Error Display Cause Verication item Solution
ERROR 6
Position overow
A command was
executed with
coordinate data that
exceeds the effective
cutting/plotting area
Execute the command
with its coordinate data
specied within the
effective cutting/plotting
area.
Congure your software
application menu to permit
Graphtec plotter control.
Re-specify the software
application’s interface
conditions.
Set the correct model
name if it was incorrect.
ERROR 7
Buffer overow
The data being input
exceeded the capacity
of the plotter’s
downloadable
character buffer,
polygon buffer, etc.
Decrease the
downloadable characters,
polygons.
ERROR 10 Invalid
I/O output request
During execution of
an output command,
another output
command was
executed.
Check the ow of your
programmed data.
ERROR 11 Invalid
byte following ESC
The ESC character
was followed by an
invalid byte.
Check the ESC
commands in your
program.
ERROR 12 Invalid
byte I/O Control
A device control
command containing
an invalid byte was
received.
Check the device control
commands in your
program.
ERROR 13 Out of
range I/O parameter
A parameter outside
of the permissible
numeric range was
specied.
Check the program.
ERROR 14 Too many
I/O parameters
Too many parameters
were received.
Check the number of
command parameters.
ERROR 15 Error in
I/O transmission
During data transfer,
a framing error, parity
error, or overrun error
occurred.
Check the settings of the
interface conditions.
ERROR 16 I/O buffer
overow
The I/O buffer
received data at a
faster pace than
it could process,
indicating that
handshaking is not
successful.
Check the settings of the
handshaking mode and
other interface conditions.
