9. TROUBLESHOOTING
Problem Cause Solution
Film can be cut but is hard to
weed afterward.
Cut lm cannot be picked up using
a retack sheet.
The retack sheet is not sticky
enough.
Switch to a retack sheet that is more
sticky.
Film gets entangled during cutting. Reduce the blade length and/or lower
the cutting FORCE.
Weeding of cut lm was postponed
too long.
Promptly weed cut lm.
Abnormal noise generated by the
cutter pen during cutting.
The lm is discolored where the
blade has passed.
Film is stuck in the tip of the cutter
plunger.
Adjust the blade length and cutting
FORCE setting.
The cutting results differ from the
specied size.
The programmable resolution
(STEP SIZE) has been set
differently at the plotter and the
software application.
Scaling has been specied at the
software application
Set both the plotter and software to
the same resolution.
Check whether scaling has been
specied.
When the plotter is receiving data,
the PROMPT lamp lights (an
offscale error occurs).
Some parts of the lm cannot be
cut.
The programmable resolution
(STEP SIZE) has been set
differently at the plotter and the
software application.
Set both the plotter and software to
the same resolution.
The computer sent coordinate
data that exceeds the specied
effective cutting area.
Set the effective cutting area to a
larger area.
The computer sent coordinate
data that exceeds the maximum
effective cutting area.
Switch to larger lm or change the
coordinate data.
The currently selected cutting
conditions are disregarded or
cannot be changed.
The Parameter Priority setting is
set to program mode.
The ENTER key was not pressed
after changing the settings.
Change the Parameter Priority setting
to manual mode.
Make sure you are setting the
conditions correctly.
Characters or lines are deformed
during pen plotting.
The plotter is in Cutting mode. Set the blade type of the cutter
OFFSET function to PEN (0).
The length of cutting results differ
from the program (slight distance
error).
The distance correction requires
adjustment.
Adjust the distance correction.
Cut characters are deformed. The Step Pass is too high. Lower the Step Pass setting.
The starting and end points of
cutting do not match.
Coordinate points are incorrectly
specied.
The Offset Cut Pressure is too
low.
The lm is too imsy.
Blade rotation is not smooth.
Check the coordinate data by plotting
it with a pen.
Raise the Offset Cut Pressure
setting.
Switch to a stronger lm.
For CB15 holder (red blade
adjustment knob), grease the cutter
blade and holder.
