FC2250-UM-251-9370 2-3
2. Description of Parts
......................... Press the [PAUSE] key to select PAUSE mode (its green lamp lights).
Press it again to cancel PAUSE mode (the lamp goes off).
Depending on the menu being displayed, this key is used to:
• Temporarily suspend a cutting or plotting operation;
• Set functions at the control panel;
• Temporarily store data received from the computer in the plotter’s buffer.
......................... After setting a function at the display panel, press the [ENTER] key to register
your setting.
To reset the plotter, concurrently press the [ENTER] and [ORIGIN] keys.
......................... Runs a cutting test to check whether the currently selected cutting conditions
are compatible with the medium loaded.
......................... Used to move the origin point.
To reset the plotter, concurrently press the [ENTER] and [ORIGIN] keys.
