FC2250-UM-251-9370 i
HISTORY OF REVISIONS
No. Date issued Description of revision Page Edition
1 07.10.10 First Printing All 01
2 08.01.09 Parts number for the vacuum panels were corrected. 10 -1 02
3 08.03.18
The dip switch setting for the Keyboard and Sensor Test Mode was corrected.
8-4, 8-17 03
4 08.03.18 Step (8) of figure was corrected. 8-17 03
5 08.08.19 Parts number for the 2-pen board was corrected. 5-1 04
6 08.09.18
Locations for the double-sided adhesive tapes were corrected.
7-14 05
7 08.10.28
Rank of parts was added.
10 -1 to 10-12 06
8 08.11.10
The dip switch setting for the Keyboard and Sensor Test Mode was corrected.
8-4 07
9 08.11.25 The display menu was corrected. 8-6,8-8,8-9 07
10 08.11.25
Explanation for the display menu and the display menu were corrected.
8-19 07
11 08.11.25 Rank for the item No.16 and No.17 were corrected. 10 -1 07
12 09.04.16 Parts number for the main board was corrected. 5-1 08
13 09.10.07
The dip switch setting for the gain input mode was corrected.
8-4 09
14 09.10.07 The Y flexible cable assembly was add to the parts list. 5-1, 10-10 09
15 09.10.07 The adjusting procedures were added. 8-2 to 8-5 09
16 09.10.07 The procedure for the gain input mode was added. 8-12 09
17 0 9.10.07
The dip switch setting for the emergency mode was added.
8-9 09
18 09.10.07 The procedure for the model selecting mode was added. 8-25 09
19 09.10.07 The silicon grease was added to the tool list. 6-1 09
20 09.10.07
The procedure for the disassembly and adjustment were added.
7-1 to 7-70 09
21 10.07.05
Parts name for the X home sensor board was corrected.
5-1, 10-6 10
22 10.07.05
Parts name for the Y home sensor board was corrected.
5-1, 10-10 10
23 10.07.05 Parts number for the writing panels were corrected. 10 -1 10
24 10.07.05 Parts number was added for the Pen Block Assembly. 5-1, 10-10 10
25 10.07.05
Parts number was added for the Y slider SH.
10-9 10
26 10.07.05
Parts number was added for the Pen Block Plate SH.
10-9 10
27 10.07.05
Parts number was added for the Pen Block Cover PM.
10-9 10
28 10.07.05 Replacement procedure was added for the Pen Block. 7-26 10
29 10.07.05 The Dip-Switch setting was added for the Pen Block (PM) 8-8 10
30 11.09.20 Parts number for the RMS HOOD was corrected. 10-10 11
31 13.07.02 Rank for the item No.2 was corrected. 10 -1 11
32 13.12.13 The note was added for the home position adjustment. 8-14 11
33 13.12.13 The wiring diagram was corrected. 11-1 11
34 13.12.16 Parts number for the X cable was corrected. 10 -1 11
35 13.12.16
Parts number for the FC2250 Pen Block Assembly was corrected.
10 -1 11
36 13.12.16 Parts number for the Control Cable was corrected. 10-4 11
37 13.12.16
Parts number for the Power Supply Relay Board was corrected.
5-1, 10-5 11
38 13.12.16
Parts number for the Notched Synchrony Belt was corrected.
10-6 11
39 13.12.16 Parts number for the X Motor was corrected. 5-1, 10-6 11
40 13.12.16
Parts number for the X Flexible Cable 60/120 was corrected.
5-1, 10-6 11
41 13.12.16 Parts number for the X Flexible Cable 180 was corrected. 5-1, 10-6 11
42 14.01.26
The table of pressure was corrected (No.2: from 24g to 48g)
8-7, 8-11 11
43 15.04.20 Parts number for the Y motor was corrected. 5-1, 10-10 12
44 15.05.21 Parts number for the F22 pulley was added. 10-9 12
