FC2250-UM-251-9730 3-11
3. OPER ATIONS
The values that can be set for each parameter are shown in the following table.
Condition Range Remarks
Cutting force
(FORCE)
Pen 1: 1 to 40
Pen 2: 2 to 80
40 steps
40 steps, even numbers only.
Cutter blade type/offset
(OFFSET)
Cutter blade type Offset
09U, 15U, 15UK30, 15-10C, 15-05S,
30U, CP002 (Creaser), CP003 (Creaser)
-5 to +5
(*1)
Other 1 to 99
CP001 (Creaser), PEN
*1
Choose 0 for automatic setting of the
optimum offset for the selected blade
type.
Speed (SPEED) 1 to 10, 15, 20, 25, 30, 35, 40 Unit: cm/s
Quality (QUALITY) 1 to 6
The lower the number, the higher the quality.
Tool No. 1, 1, 2
(3) Press a key from [F1] to [F4] to move the blinking cursor to the parameter that you wish to set.
(4) Change the setting value of the parameter that you wish to set.
(5) Press the [ENTER] key to register the setting conditions in the plotter’s internal memory. To cancel your
settings, press the [NEXT] key.
(6) Press the [TEST] key to perform test cutting. Make any adjustments required by changing the settings to
suit the media type and thickness.
Use the [TEST] key to perform test cutting. Adjust the OFFSET value to suit the type and thickness of
the medium being used, and ne-adjust the nish of the corner sections.
• If [OTHER] has been specied as the blade type, the OFFSET value can be set in a range of 1 to 45.
• The OFFSET value is not displayed for plotting mode.
• Your settings are retained even while the plotter is turned off.
• The FORCE and SPEED values, in particular, should be initially set to low values and gradually raised
while running cutting tests.
(7) Press the [F4] key to return to the previous display.
