FC2250-UM-251-9370 7-24
7. DISASSEMBLY AND ADJUSTMENT
(6) Remove the two M3L6 binding head screws holding the X exible cable relay board cover, then detach
the X exible cable relay board cover.
X exible cable relay board cover
M3L6 binding head screw
(7) Disconnect the X exible cable from the X exible cable relay board.
X exible cable
X exible cable relay board
How to reinstall the X exible cable
(1) Reattach the X exible cable in the reverse order in which it was detached.
To Next Page
