268
Program description - Basic settings
Use the selection keys of the left or right four-way
button to select the “Stick mode” line. The option field
will be framed.
3
–––7
Cn6
Basic settings
Vario Vol
Beeps Vol
Own
2
3
H-J Sandbrunner
1
SEL
Stick mode
Tap on the SET key briefly. The currently displayed
stick mode will be displayed in inverse video. Now use
the selection keys of the right four-way button to select
the variant, from 1 to 4, you most frequently use. In the
future this will be used for newly initialized model mem-
ories, but can be changed on an individual basis for up
to 20 respectively 24 model memories.
Following a simultaneous tap on the or keys
of the right four-way button (CLEAR), the display will
return to stick mode “1”.
With another tap on the SET key, the selection field
will be deactivated again to permit a change to another
line.
(Pre-set) Modulation
Standard equipment for the
mc-16 HoTT and mc-
20 HoTT transmitters includes a HoTT transmitter
module and, under the left front cover – as viewed from
the front – a DSC jack and a DATA jack, see page 24.
It is also possible to switch between three RF mod-
ule variants in the “Module” line of the »Base setup
model« menu – see pages 79 and 89 – by select-
ing “HoTT”, “EXT.” or “SP.” for each model memory
separately. The most frequently used variant should
logically be selected for the “Pre-set modulation” line in
the »Basic settings« menu.
In the future this will be used for newly initialized model
memories, but can be changed on an individual basis
for up to 20 respectively 24 model memories.
Briefly tap the centre SET key of the right four-way
button:
3
Basic settings
Beeps Vol
Own
2
3
H-J Sandbrunner
1
SEL
Stick mode
Modulation HoTT
Now use the selection keys of the right four-way button
to select the variant from among “HoTT”, “EXT.” and
“SP.”.
A simultaneous tap on the or keys of the right
four-way button (CLEAR) will return the display back to
modulation “HoTT”.
With a brief tap on the SET or ESC key, the selected
field is deactivated to permit a switch to another line.
(Pre-set) DSC Output
In the line with the same name in the »Basic set-
tings, model« menu, page 85 or 95, a separate
specification can be made from among the four avail-
able modulation types which is specific to each model
memory and will then provided at the DSC socket.
This choice primarily influences the maximum number
of control channels which can be attached to the DSC
(direct servo control) socket, and thus also available to
a flight simulator or teacher/pupil system. By select-
ing “PPM10” this will be control channels 1 … 5, for
“PPM16” channels 1 … 8, for “PPM18” channels 1 …
9 and for “PPM24” channels 1 … 12:
SEL
Rcv Ch Map R12
R08
Base setup model
RF transmit ON
RF Range Test 99sec
DSC Output PPM10
In a manner similar to “(Pre-set) Stick mode”, in this
»Basic settings« menu the selection made for the
“(Pre-set) DSC Output” line will determine which of the
four possible modulation types will be adopted as the
default variant for a newly initialized model memory.
If necessary, use the selection keys of the left or
right four-way button to switch to the “DSC Output”
line then, with a brief tap on the centre SET key of the
right four-way button, activate the value window:
Basic settings
Own
H-J Sandbrunner
1
SEL
Stick mode
Modulation HoTT
DSC Output
PPM10
Now a choice can be made from among the four pos-
sible modulation types: “PPM10”, “PPM16”, “PPM18”
and “PPM24”, with the selection keys of the right four-
way button. Another tap on the centre SET key of the
right four-way button will conclude the entry.
A simultaneous tap on the or keys of the right
four-way button (CLEAR) will reset this option back to
“PPM10”.
