Program description - Basic settings
(Pre-set) Pitch min (only relevant to helicopter models)
In a manner similar to the previously described options
“Stick mode” and “DSC Output”, enter the preferred
actuation direction for the throttle/pitch stick on this
line so the choice will already be present by default
for model memories newly initialized in the future. The
functionality of all other helicopter program options (to
the extent they affect throttle and/or pitch) are depend-
ent on this setting; in other words the throttle curve,
idle trim, Channel 1 tail rotor mixer, etc.
This means:
• “forwrd”
minimum front pitch setting, the pitch stick (C1)
points away from the pilot.
• “back”
minimum rear pitch setting, the pitch stick (C1)
points towards the pilot.
A simultaneous tap on the or keys of the right
four-way button (CLEAR) will set this option to “back”.
Note:
The C1 stick’s control direction for “Throttle
min front/rear” in the xed-wing program can
be changed individually in the »Model type«
menu.
LCD Contrast (upper display / lower display)
In assure optimal legibility of the transmitter
mc-16
HoTT or mc-20 HoTT displays under all weather
and temperature conditions, their contrast settings can
be adjusted separately.
mc-16 HoTT
The contrast of the front screen of the
mc-16 HoTT
transmitter – located between the switch boards – can
be adjusted as follows: select the “LCD Contrast” line
using the Select buttons of the left or right-hand four-
way button, and then briefly press the central SET
button of the right-hand four-way button:
Basic settings
SEL
Modulation HoTT
DSC Output PPM10
LCD Contrast
0
Pitch min back
Now display contrast can be adjusted in the value field
displayed in inverse video within a range of ±20 by us-
ing the selection keys of the right four-way button:
Basic settings
SEL
Modulation
HoTT
DSC Output
PPM10
LCD Contrast
Pitch min back
–15
Basic settings
SEL
Modulation
HoTT
DSC Output
PPM10
LCD Contrast
Pitch min back
+15
mc-20 HoTT
Contrast for the forward display of the transmitter
mc-20 HoTT, located between the switch panels, is
adjusted by selecting the “Top LCD contrast” line with
the selection keys of the left or right four-way button
then briefly tapping on the centre SET key of the right
four-way button.
Basic settings
SEL
Modulation HoTT
DSC Output PPM10
Top LCD Contrast
0
Pitch min back
Now display contrast can be adjusted in the value field
displayed in inverse video within a range of ±20 by us-
ing the selection keys of the right four-way button:
RX–S QUA: 100%
RX–S STR: 100%
TX–dBm: –33dBm
RX–dBm: –33dBm
RX–VOLT:4.8V TMP
L–PACK: 10ms
CH OUTPUT TYPE:ONCE
R-LOW V:4.6V +22°C
RX–S QUA: 100%
RX–S STR: 100%
TX–dBm: –33dBm
RX–dBm: –33dBm
RX–VOLT:4.8V TMP
L–PACK: 10ms
R-LOW V:4.6V +22°C
Contrast for the rear display, located between the four-
way buttons, is adjusted by selecting the “Bottom LCD
contrast” line with the selection keys of the left or right
four-way button then briefly tapping on the centre SET
key of the right four-way button.
Basic settings
SEL
DSC Output PPM10
Top LCD Contrast
0
Pitch min back
0
Bottom LCD Contr.
Now display contrast can be adjusted in the value field
displayed in inverse video within a range of ±20 by us-
ing the selection keys of the right four-way button:
