GRAUPNER mc-16 Programming Manual

307
Programming examples - Using ight phases
Whether or not one of the phases 1 … 7 currently has
an assigned switch and the state of the switch can be
seen in the “status” column at the second column from
left:
Symbol Meaning
– No switch assigned
+ Phase can be called via switch

Indicates the currently active phase
Since, except for phase 1, all other phases are still des-
ignated with a “–” symbol, now switch in the menu …
»Phase assignment« (page 154)
… and assign the previously defined flight phases
to appropriate switches with which a selection from
among three phases is possible.
Since there is no particular priority here, assign for
example switch “C” in the display to one of the two end
settings of one of the two 3-way switches.
Thus activating the switch assignment as described in
“transmitter controls, switches and control switch as-
signments” on page 60 and assign the selected switch
from the middle position. Afterward put the selected
switch again into its middle position, activate the switch
assignment under “D” then move the selected 3-way
switch again out of its middle position and into the
other end position, as shown below:
Phase assignment
A B
C D E F
1 normal
2
6
5
prior
combi
After the switch assignment is complete, use the se-
lection keys to switch to the bottom right and activate
the assignment of phase names with a brief tap on the
centre SET key of the right four-way button.
Now close for example switch “6” by moving the se-
lected 3-way switch forward.
Assign the name “<2Thermal>” to this switch position
and leave the name of its “OFF” position as “<1nor-
mal>”.
A B
C D E F
2
6
5
2 Thermalv
Phase assignment
prior
combi
A B
C D E F
2
6
5
1 normal
Phase assignment
prior
combi
Finally, move the 3-way switch to the rear toward
“5”-position and assign this switch position the name
“<3 Speed>”:
A B
C D E F
2
6
5
3 Speed
Phase assignment
prior
combi
The phase names selected in the programming are
now shown, depending on the switch status, in all
flight-phase dependent menus, see the table on
page146.
Since we have already made some settings in flight-
phase dependent menus, such as in the »Wing mix-
ers« menu, we will now copy these settings to the
«Thermal» flight phase. For this purpose, open the
menu …
»Copy/Erase« (page 72)
… and switch to the “Copy flight phase” line:
=>
=>
=>
=>
=>
=>
=>
Copy flight phase
Erase model
Copy model–>model
Export to SD
Import from SD
All seven possible flight phases are listed in “Copy from
phase”:
Select the flight phase to be copied, e. g. “1Normal”.
7
Copy from phase:
3
5
=>
=>
2
4
6
1
normal Thermal
Speed
With a brief tap on the centre SET key of the right four-
way button, switch the window to entry of the target
memory “Copy to phase”.
Select phase “2 Thermal” as the target:
7
Copy to phase:
3
5
=>
=>
4
6
1
normal
Speed
Thermal2
Confirm the selection with a brief tap on the centre
SET key of the right four-way button.
A security query follows, who should be confirmed with
“Yes”:
