2.output shaft and gear assembly
The assembly procedure of output shaft and gear assembly (Refer to Figure 8.19),is shown as follows:
a. Check the output shaft bush for damage, replace it if necessary.
b. Check the parking detent on the ring gear for damage ; replace it if necessary.
c. Check the sealing ring groove for damage.
d. Use the automatic transmission liquid to lubricate the gasket.
e. Place the scarfing notch upwardly and install the sealing ring on the output shaft.
f. If has been removed., it should use the ring spring for reinforcement when install the ring gear on the output shaft. Ensure the
ring spring is fixed in the groove.
g. Use the Vaseline oil for lubrication; install the thrust bearing assembly NO.10 on the output shaft.
h. It should be carefully when install the output shaft on the box to avoid the damage of sealing ring.
3. Rear brake belt assembly
The assembly procedure of rear brake belt assembly (Refer to Figure 8.18) is shown as follows:
a. Check the rear brake belt for leakage or damage; check its corresponding bush and metal back .
Figure 8.18 Rear servo and brake belt
b. Install the reaction reinforcement bar on the main box, need not shim.
Caution:
Place the new brake belt in the automatic transmission liquid for about 5 minutes before install it.
c. It should be careful when install the rear brake belt on the transmission. Ensure the brake belt is installed on the correct
position.
d. Install the application support bar on the rear brake belt, then connect it to the servo motor
bar.
e. Install the cam disc and tighten the screw according to the instruction.
