Installation of ball pin
1. Install the upper ball pin on the upper arm
Tightening force: 78 5N m
2. Install the lower ball pin on the lower arm
Tightening force: 140 10N m
3. Install the steering knuckle and front hub assembly
(Refer to section Front Hub and Steering Knuckle)
Disassembly of ball pin
(Refer to section “Front Hub and Steering Knuckle”)
2. Remove the lower ball pin form the lower arm
3. Remove the upper ball pin from the upper arm.
