30. Remove the drive bevel gear, then take out the
adjusting washer under spacer.
Check and replacement of reducer
1. Replace the big bearing of drive bevel gear .
a. Use the special tools to press out the big bearing of drive
bevel gear.
Caution: It should replace the drive and driven bevel gear in
pair before replace the big bearing if the drive bevel gear is
damaged.
special
special
special
b. Install the washer on the drive bevel gear, Use the special
tools to install the new big bearing .
2. Replace the big bearing outer race of drive bevel
gear.
a. Use the brass bar and hand hammer to knock down the big
bearing outer race.
b. Use the special tools to press in the new big bearingouter race.
Special tools
