Brake-11
8. Install the new brake block
a. Install a wear limitation alarm plate of brake block on the inner
brake block.
b. Install a silencing plate and a silencing plate combination on the
inner brake block.
c. Install a silencing plate combination on the on the outer brake
block.
d. Install two brake blocks; let the wear limitation alarm plate is in
the inside of brake caliper.
Caution: It is unallowable that the operating surface of brake
block and brake disc is polluted by the grease and paint.
e. Suck a few of brake fluid form the liquid reservoir (prevent the
brake fluid from overflowing from liquid reservoir).
f. Use the special tools to press the piston .
9. Install the brake pump
Install and tighten the hexagon flange bolt.
Tightening force: 25
35N m
Remarks: Only can replace the brake block on a wheel in one
time to avoid the piston on another wheel is pushed out.
10. Install the front wheel
Tightening force of the wheel fixing nut is 120N
m
11. Check whether the brake fluid level is in the specified position.
