Front hub
Disassembly of front hub
1. Remove the disc brake
Remove the brake caliper and hang it by steel cable.
Remarks: Do not remove the brake pipe and brake hose.
2. Remove the hub cap
Use the inner hexagon spanner to screw off the fastening blot and
remove the hub cap.
3. Remove the hub and brake disc
a. Use the Philips screwdriver to screw off the lock screw and
remove the lock washer.
b. Use the special tools to remove the lock nut.
c. Remove the hub and brake disc with the external bearing.
special tools
