Constant-speed drive shaft assembly
Installation and disassembly drawing of front drive shaft assembly on front drive axle
hanger plank R
universal-joint bearing
front reducer and electric clutch assembly
Power plug of electric clutch
circlip
hanger plank L
constant-speed drive shaft
circlip
lower segment of vent tube of front drive axle
circlip
circlip
Pregummed component
N m: specified torque
universal-joint oil seal
universal-joint bearing
constant-speed drive shaft assembly
