Safety airbag-20
Wiring harness joint (instrument cluster wiring harness)
Check whether the wiring harness is well installed, the joint is broken and the terminal is deformed.
Warning
The attentions for use and maintenance for SRS safety airbag are displayed in the Figure. Operate according to the sign and, the
destructed and dirty sign must be replaced with a new one steering
wheel in Figure6-1
Driver’s side safety airbag module in Figure 6.2
Clock spring in Figure 6.3
SRS-ECU in Figure 6.4
Sun visor in Figure 6.5
Passengers’ side safety airbag module in Figure 6.6
Passenger side airbag (PAB)
