special tools
diagram of special tools
grease
4. Remove the oil seal and inner bearing
a. Use the screwdriver to pry out the oil seal.
b .Remove the inner race of inner bearing from the hub.
Check and repair of front hub
1. Check each bearing
Wash the inner and outer race of each bearing and check them for
damage or wear.
2. Replace the bearing outer race
a. Use the brass bar and hand hammer to knock out the bearing outer
race.
b. Use the special tools to knock in the new bearing outer race.
Assembly of front hub
1. Coat the inner surface of hub and bearing outer race
with the grease.
The grease is the Jin HP-R grease or the grease met the requirement in
following table.
Item Typical data
Dropping point, C
289
Leakage amount (104
C, 6h), g 0.48
EP performance OK value , N
178
