c.Use the special pneumatic pliers to lock the large and small clip of
outer jacket.
d.Ensure the jacket of both sides does not be prolonged or shortened
when the front drive shaft has the standard length.
Standard length: 400.5mm
If only need to replace the outer components of front drive
shaft assembly on car, it can remove the left and right steer-
ing knuckle of car, then disconnect the inner trumpet con-
nector of front drive shaft assembly, then take out the three-
pin section assembly and shaft from the inner trumpet con-
nector for replacement.
Installation of constant-speed drive shaft assem-
bly on front drive axle
1. Insert the hanger plank into the drive shaft, inserted
with oil seal; use the circlip pliers to install the inner
circlip.
Caution: It should replace the oil seal if damaged.
special tools
circlip pliers
support the lower end
