4. Installation of longbushoflowersuspensionarmUse
the special tools to install the new bush.
Remarks: Do not coat the bush with the grease.
Installation of lower suspension arm
1. Installation of lower suspension arm
a. Install the rear shaft of lower arm and tighten the nut to the
specified torque.
Tightening force: 290
25N m
b. Install the front shaft of lower arm and screw on the nut
temporarily.
2. Installation of front hub and steering knuckle
assembly
(Refer to section “Front Hub and Steering Knuckle”)
3. Install the vibration damper on the lower suspension
arm.
Install the vibration damper on the lowersuspensionarmbracket.
Tightening force: 90 10N m
4. Connect the stabi lizerbar to the lower suspension
arm
Tightening force: 63 5N m
special tools
