Replacement of major semiaxle oil seal
1. Make the electric clutch is in the 4WD status,
them stop the engine and remove the front drive
axle assembly (see the disassembly of front reducer
assembly)
2. Use the wrench to screw off the bolt which fix the
front axle vent tube connectorassemblyonventtubeb
racket bolt
3. Disconnect the connector between vent tube of
electric clutch housing and front drive axle vent tube
connector assembly
4. Disconnect the connector between the vent tubes
on the electric clutch and vent tube connector
assembly.
5. Remove the bolt which is used to fix the electric
clutch housing and front axle tube flange; use the
brass bar to open the electric clutch housing and take
out the mechanical wheel of separator.
Caution: The lubrication oil will flow out when sepa-
rate the electric clutch housing from the front axle
flange. It should use the container to hold it.
mechanical wheel of separator
disconnect the place
disconnect the place
