Replacement of upper arm bush
1. Remove the bush
a. Remove the bolt and washer.
b. Use the special tools to push out the bush.
c. Remove the upper arm shaft; remove another bush in same proce-
dure
2. Install the bush
a. Use the special tools to press in the bush.
b. Install the upper arm shaft; use the special tools to press inanother
bush.
3. Tighten the upper arm shaft to specified torque.
a. Coat the screw of both ends of upper arm shaft with the screw
lock sealant; install the washer and nut.
Remarks: Adjust the position of upper lower; make the installa-
tion plane of ball pin is vertical to the installation plane of upper
arm shaft.
special tools
special tools
special tools
