Specified torque : 200-220N m
Caution: Drip 1-2 drop of screw lock agent on the middle front
part of the lifting bolt
10 Use the bolt to connect the front drive axle flange
and drive shaft according to the mark mage before
disassembly and tighten it to the specified torque.
specified torque: 73-83N.m
11. Install the beam under the front drive axle.
Tighten the beam connecting bolt to the specified
torque.
specified torque: 73-83N.m
