7. Use the circlip pliers to remove the circlip fixed
the major semiaxle bearing outer race.
8. Use the special tools to pull out the major semiaxle
and major semiaxle bearing with the major semiaxle
inner race circlip.
(Refer to “Replacement of Major Semiaxle Oil Seal”)
9. Use the special tools to remove the major semiaxle
oil seal.
(Refer to “Replacement of Major Semiaxle Oil Seal”)
10. Pull out the vent tube on the front axle tube.
11. Use the circlip pliers to remove the circlip. Fasten
the major semiaxle bearing inner race.
12. Press out the major semiaxle bearing on press
machine. (Or knocked out by hand hammer)
Caution: Don’t damage the end spline of major
semiaxle.
13. Use the special tools to pull out the needle bear-
ing in major semiaxle.
Caution: It should use the pad when use the vise to
clamp the major semiaxle.
14. Use the wrench to remove the bolt which is used
to fix the clump weight and axle bush assembly, take
off the clump weight and axle bush assembly.
special tools
