Safety airbag-17
Passengers’ side failure
Failure code
$9015
$9016
$9018
$9019
Passengers’ side safety airbag module (high or low resistance or shorting grounding)
Test condition
Warning
If not correctly handled, the safety airbag module as well as pretension safety belt may possibly be
trigged, released and tensioned, thus make serene damage to people. Therefore, please carefully read the
repairing warning before trouble handling. Please take references in safety airbag system repairing warning
If with passengers’ side safety airbag failure
The resistance between SRS safety airbag system unit connector clip stitch 13 and stitch 14 not within the
designated scope.
The wiring harness shorting between safety airbag system unit stitch 13 and stitch 14
Open loop between SRS safety airbag system unit connector clip stitch 13 and stitch 14,
Possible causes
Passengers’ side safety airbag module failure
The failure of connector clip between passengers’ side safety airbag module and SRS safety airbag system
electronic-control unit
The failure of connector clip between SRS safety airbag system unit and grounding jumper.
The circuit shutoff or shorting between passengers’ side safety airbag module and SRS safety airbag system
electronic-control unit
The circuit shutoff or shorting between SRS safety airbag system unit and grounding jumper
SRS safety airbag system unit failure
Procedure Test Operation
Yes Next step
1
Is the vehicle with passengers’ side safety airbag module
No Step 5
Yes
Present failure code
Next step
History- accumulated failure codes
Next step
2
Check passengers’ side safety airbag connector clips
Warning
If not correctly handled, the safety airbag module may possibly be
trigged and released thus cause serene damage to people, therefore,
please carefully read the maintenance warning.
Take references in safety airbag maintenance warning.
Place the ignition switch in LOCK position
Release accumulator negative wire and wait for about 1 minute
plus
Remove the PAB trim cover, glove box (passengers’ side safety
airbag is under the trim cover)
Release passengers’ side safety airbag module connector clip
Is the previous connector clip normal?
No Replace the wiring harness
Yes
Next step
3
Confirm whether the failure cause is with passengers’ side safety
airbag module or some other parts
Connect a better module to the terminal A and B of passengers’
side safety airbag connector clip
Connect the accumulator negative wire
Place the ignition switch in ON position
Any failure code in display?
No
Replace passengers’ side safety airbag
module
Take references in the
removal/installation of passengers’ side
safety airbag module in safety airbag
system.
To Next Page
